Open Source Strong Motion Network Densification

Grillo One

Proven open source seismic sensor for earthquake early warnings. Ideal for complementing existing seismic networks with strong motion detection. Hardware and software designs are fully open source.

Open source hardware & software
Ultra-low power consumption
Ultra low-noise MEMS triaxial accelerometer (20-bit)
Ethernet/WiFi connectivity
Real-time data transmission

Buy Now View Technical Specs

Grillo One Features

Our standard seismic seismometer comes with these essential capabilities

Open Source Design

Fully open source hardware and software. Access all designs, schematics, and code on GitHub.

View on GitHub →

Ethernet/WiFi Connectivity

Flexible connectivity options allow for easy integration into existing networks and infrastructure.

MEMS Accelerometer

High-precision MEMS accelerometer provides accurate seismic activity detection and measurement.

All-in-one Solution

Everything included for operation with MEMS sensor - no need for digitizer or additional computing module.

Integrations

Configured to transmit directly to your seismic data acquisition system (Earthworm, SeisComP, Python, or Grillo Cloud).

Grillo One Specifications

Detailed technical information about this product

Physical

Dimensions 50x80mm (PCB)

Weight 20g

Enclosure 3D printed or IP65 Outdoor (optional)

Operating Temperature -20°C to +60°C

Power

Power Source AC Adapter (5V DC)

Power Consumption 1.32W (400mA at 3.3V)

USB Power and firmware updates

Connectivity

Primary Connection Ethernet

Secondary Connection WiFi 802.11 b/g/n 2.4

Data Transmission Real-time

Timing NTP

Sensors

Primary Sensor MEMS triaxial accelerometer with 20-bit ADC

Noise Density 22.5µg/√Hz

Full-Scale Range ±2g

Sampling Rate 125 Hz

Detectable Events Microseismic to strong local earthquakes

Real-World Application

See how our technology is making a difference

Mexican Earthquake Early Warning System in Oaxaca

Oaxaca & Guerrero, Mexico

USAID & AXA Insurance

Real-time seismic monitoring and early warning

Mexican Earthquake Early Warning System in Oaxaca

In partnership with USAID and AXA Insurance, Grillo One sensors have been deployed across Oaxaca and Guerrero, Mexico to strengthen the country's earthquake early warning capabilities. This implementation provides critical coverage in two of Mexico's most seismically active regions, delivering real-time alerts to vulnerable communities and enabling rapid emergency response.

“The Grillo One network has proven its capability by detecting and characterizing seismic events, providing crucial early warning time for communities across Oaxaca and Guerrero.”

Sam , USAID Development Innovation Ventures

Compare with Other Products

See how Grillo One compares to our other seismic monitoring solutions

Features	Grillo Pulse	Grillo One
Ethernet
WiFi
LTE (available)/Starlink (future)	Optional	✗
Timing	GPS/NTP	GPS/NTP
Power Source	Solar/USB/DC	USB
Battery Backup
Sensors	MEMS + Geophone	MEMS Accelerometer
Off-grid Operation
IP65 Outdoor Case	Optional	Optional
Integration	Earthworm, SeisComP, Python, Grillo Cloud	Earthworm, SeisComP, Python, Grillo Cloud
	Buy Now	Buy Now

Ready to deploy Grillo One?

Get in touch with our team to learn how our standard seismic seismometer can help protect your community or organization.

Buy Now Learn More
